Product Overview
DORLAND System Control Tech Co., Ltd. has recently launched the intrinsically safe intelligent industrial explosion-proof PAD Ex Tablet 09 Plus, which adopts advanced technology, intrinsically safe circuit design, domineering appearance, and sturdy body. This PAD adopts an 11 inch touch screen design and is equipped with a rear triple camera 48MP+20MP+5MP pixel camera. Its waterproof and dustproof performance meets the international IP68 standard.
In addition, we have also equipped various outdoor construction and pipeline inspection functions such as GPS/Beidou/Glonass/Galileo within the PAD, which can be used in conjunction with OA office systems, inspection positioning systems, data acquisition systems, and other applications. Especially suitable for harsh environments with hazardous explosions, such as petroleum, chemical, pharmaceutical, oil depots, tank farms, and other hazardous areas with flammable and explosive gases, facilitating timely communication between users, production, and scheduling.
Technical Specifications
| Ex-marking: | Ex ib IIC T4 Gb / Ex ib IIIC T130℃ Db |
| Certificate No.: | CCRI 23.2102X |
| IP Grade: | IP68 |
| OS: | Android 13.0 |
| CPU: | MTK G99 （MT6789）Octa Cores，2*2.2 GHz–Cortex-A76 + 6*2.0 GHz–Cortex-A55 |
| Front Camera: | 32MP |
| Rear Camera: | 48MP (main camera)+20MP (night vision)+5MP (macro camera) |
| Screen: | 11 inches, FHD， Resolution 1200 * 1920 |
| Memory: | 6GB RAM (RAM+additional 6GB expansion)+256GB ROM |
| TF card: | Supports up to 2TB expansion |
| Battery: | 20000mAh/3.85V |
| Frequency band: | GSM: B2/B3/B5/B8 CMDA：BC0/BC1/BC10 WCDMA:B1/B2/B4/B5/B6/B8/B19/ FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B18/B19/B20/B25/B26/B28A/B28B/B66 TDD:B34/B38/B39/B40/B41 EDGE/GPRS: Support |
| GPS: | GPS+Glonass+Beidou+Galileo |
| Wi-Fi: | 802.11 a/b/g/n/ac（2.4G+5G)， Design compatible with ax (WIFI6） |
| Bluetooth: | BT5.1 |
| NFC: | Support |
Highlights & Features
Intrinsically Safe Explosion-proof——Suitable for multiple flammable and explosive hazardous environments such as petroleum, chemical, maritime, etc
Big Screen——11 inches 1200 * 1920
High protection level——IP68 and 1.5-meter drop protection can be used in harsh working environments
High-capacity battery——20000mAh battery can ensure long-term endurance
Applications
Suitable for on-site photography, mobile office, inspection, and work permit management in flammable and explosive hazardous environments.
