Product Overview
DORLAND System Control Technology Co., Ltd. recently launched Industrial high-protection explosion-proof camera EX Rugged Camera 06, which uses a 48 megapixel image sensor, 18X digital zoom, and three focusing methods to clearly present near and far scenes.
In addition, the device is also suitable for outdoor construction, pipeline inspection, etc., and can be used in conjunction with various applications such as OA office systems, inspection positioning systems, data acquisition systems, etc. Especially suitable for harsh environments with hazardous explosions, such as petroleum, chemical, pharmaceutical, oil depots, tank farms, and other hazardous areas with flammable and explosive gases, facilitating timely communication between users, production, and scheduling.
Key Technical Specifications
| Ex-marking: | Ex ib IIC T4 Gb/Ex ib IIIC T130 ℃ Db |
| Certificate No.: | CLEx26.5554X |
| IP Grade: | IP68 |
| Image sensor: | 48 million/IMX586 |
| Display screen: | 2.83-inch main screen+2.01-inch small screen |
| LED fill light: | Support |
| Storage medium: | Memory card |
| File format: | Video: MOV Image: JPG |
| Photo resolution: | 5M/8M/12M/20M/26M/24M/32M/48M/64M/70M/80M/90M |
| Video resolution: | HD720P/30(60)Fps，FHD1080P/30(60)FPS，2.7K/30Fps4K/30Fps，4K/60Fps，5K/30Fps，6K/25Fps，8K/15Fps |
| Video recording mode: | Recording/loop recording/time-lapse recording/stabilization |
| Photography mode: | Scheduled photography/continuous photography/normal photography |
| Digital zoom: | Digital zoom 18X |
| Focusing method: | Semi automatic/fully automatic/fixed focus |
| Anti shake: | Support (electronic image stabilization) |
| Dimension: | 123*44.6*81mm |
| Weight: | 292g (including battery) (bare machine) |
| Interface: | TYPE-C |
Highlights & Features
Intrinsically Safe Explosion-proof——Suitable for multiple flammable and explosive hazardous environments such as petroleum, chemical, maritime, etc
High protection level——IP68（10m，30min）
High megapixel——90MP Photograph、8K Video
Applications
Suitable for on-site photography, mobile office, inspection, and work permit management in flammable and explosive hazardous environments.
