Product Overview
Dorland System Control Tech Co. Ltd., has recently launched the intrinsically safe intelligent industrial grade explosion-proof mobile phone EX_08 PRO, which features an intrinsically safe circuit design, a powerful appearance, and a sturdy body. The device features a 6.6-inch main screen and a 1.45-inch secondary screen, equipped with a 32MP (front)+108MP (rear)+24MP (rear night vision) camera, and its waterproof and dustproof performance meets the international IP68 standard.
In addition, the device features fingerprint unlocking on the side and comes standard with NFC, meeting the reading and writing needs of various scenarios. We have also configured various functions such as Beidou+Galileo+Glonass+GPS positioning inside the phone, which are suitable for outdoor construction, pipeline inspection, etc. It can be used in conjunction with OA office systems, inspection positioning systems, data acquisition systems, and other applications. Especially suitable for harsh environments with hazardous explosions, such as petroleum, chemical, pharmaceutical, oil depots, tank farms, and other hazardous areas with flammable and explosive gases, facilitating timely communication between users, production, and scheduling.
Key Technical Specifications
| Ex-marking: | Ex ib IIC T4 Gb / Ex ibD 21 T130℃ |
Certificate no.: | CCRI 21.2840 |
IP Grade: | IP68 |
OS: | Android 15.0 |
Screen: | 6.6-inch main screen 1080 * 2408 IPS FHD+, 1.45-inch secondary screen, 240 * 240 |
Memory: | 8GB RAM (+RAM expansion of 16GB)+512GB ROM |
Platform: | Helio G100 (MT6789) 8-core, 2 * A76 2.2GHz+6 * A55 2.0GHz |
Camera: | 108MP (main camera)+24MP (night vision) 32MP (Front) |
Battery: | 8500mAh |
Frequency: | 2G: B2/B3/B5/B8 3G: B1/B2/B4/B5/B8/BC0/BC1/BC10/B19 4G: B34/B38/B39/B40/B41/B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B18/B19/ B20/ B25/B26/B28A/B28B/B66/B71 |
Size: | 174.6*82.3*12.8mm |
WIFI: | Support |
NFC: | Support |
Navigation: | Beidou,Galileo,Glonass,GPS |
Bluetooth: | 5.0 |
Highlights & Features
Intrinsically Safe Explosion-proof——Suitable for multiple flammable and explosive hazardous environments such as petroleum, chemical, maritime, etc
High protection level——IP68 and 1.5-meter drop protection can be used in harsh working environments
High resolution shooting——32MP front camera+108MP main camera
Dual screen display——6.6-inch main screen+1.45-inch secondary screen
Applications
Suitable for on-site photography, mobile office, inspection, and work permit management in flammable and explosive hazardous environments.
